TheWizards APT group uses SLAAC spoofing to perform adversary-in-the-middle attacks

In this blogpost, ESET researchers provide an analysis of Spellbinder, a lateral movement tool for performing adversary-in-the-middle attacks, used by the China-aligned threat actor that we have named TheWizards. Spellbinder enables adversary-in-the-middle (AitM) attacks, through IPv6 stateless address autoconfiguration (SLAAC) spoofing, to move laterally in the compromised network, intercepting packets and redirecting the traffic of legitimate Chinese software so that it downloads malicious updates from a server controlled by the attackers.

Key points in this blogpost:

• We discovered a malicious downloader being deployed, by legitimate Chinese software update mechanisms, onto victims’ machines.
• The downloader seeks to deploy a modular backdoor that we have named WizardNet.
• We analyzed Spellbinder: the tool the attackers use to conduct local adversary-in-the-middle attacks and to redirect traffic to an attacker-controlled server to deliver the group’s signature backdoor WizardNet.
• We provide details abouts links between TheWizards and the Chinese company Dianke Network Security Technology, also known as UPSEC.

Overview

In 2022, we noticed that a suspicious DLL had been downloaded by the popular Chinese input method software application known as Sogou Pinyin. The DLL, named after a legitimate component of that software, was a dropper for a downloader that retrieved an encrypted blob from a remote server. The blob contained shellcode that loads the backdoor we have named WizardNet.

Our research led to the discovery of a tool, used by the attackers, that is designed to perform adversary-in-the-middle attacks using IPv6 SLAAC spoofing to intercept and reply to packets in a network, allowing the attackers to redirect traffic and serve malicious updates targeting legitimate Chinese software.

Victimology

TheWizards has been constantly active since at least 2022 up to the time of writing. According to ESET telemetry, TheWizards targets individuals, gambling companies, and unknown entities in the Philippines, Cambodia, the United Arab Emirates, mainland China, and Hong Kong. Its geographical distribution is shown in Figure 1.

Spellbinder, the IPv6 AitM tool

We initially discovered and analyzed this tool in 2022, and observed a new version with a few changes that was deployed to compromised machines in 2023 and 2024. Once the attackers gain access to a machine in a targeted network, they deploy an archive called AVGApplicationFrameHostS.zip, and extract its components into %PROGRAMFILES%\AVG Technologies. The files include:

• AVGApplicationFrameHost.exe
• wsc.dll
• log.dat
• winpcap.exe

Next, the attackers install winpcap.exe and run AVGApplicationFrameHost.exe. The latter, originally named wsc_proxy.exe, is a legitimate software component from AVG that is abused to side-load wsc.dll; this DLL simply reads the shellcode from the file log.dat and executes it in memory. The shellcode decompresses and loads Spellbinder in memory.

Spellbinder uses the WinPcap library to capture packets and to reply to packets when needed. The first task is to select or find an adapter with which to perform the packet capture. The code uses the WinPcap API pcap_findalldevs to get all available adapter devices. The devices are itemized in a numbered list for the attacker. Optionally, Spellbinder accepts, as an argument, an index that can be used to pick one adapter from this list. If a device is not supplied, Spellbinder uses the Windows APIs GetBestInterface and GetAdapterInfo to find a suitable adapter, and prints its information on screen.

Figure 2 shows the output of Spellbinder when no item number is supplied. In that case, the tool finds the most suitable adapter by itself.

As shown in Figure 3, once an adapter is found, Spellbinder uses the WinPcap pcap_open_live API to start capturing packets, and creates two threads: one to send ICMPv6 Router Advertisement packets (explained in the next section), and a thread to monitor network changes. The WinPcap pcap_loop API does the job of invoking a callback function from Spellbinder every time a new packet is captured.

Router Advertisement thread

This attack vector was discussed by the IETF as early as 2008 and is caused by a commonly overlooked network misconfiguration of IPv4 and IPv6 coexistence. It was then thoroughly detailed in 2011 by Alec Waters, who dubbed it the SLAAC Attack. It takes advantage of IPv6’s Network Discovery Protocol in which ICMPv6 Router Advertisement (RA) messages advertise that an IPv6-capable router is present in the network so that hosts that support IPv6, or are soliciting an IPv6-capable router, can adopt the advertising device as their default gateway.

Spellbinder sends a multicast RA packet every 200 ms to ff02::1 (“all nodes”); Windows machines in the network with IPv6 enabled will autoconfigure via stateless address autoconfiguration (SLAAC) using information provided in the RA message, and begin sending IPv6 traffic to the machine running Spellbinder, where packets will be intercepted, analyzed, and replied to where applicable. Figure 4 illustrates the first stage of the attack.
