PlushDaemon compromises supply chain of Korean VPN service

ESET researchers provide details on a previously undisclosed China-aligned APT group that we track as PlushDaemon and one of its cyberespionage operations: the supply-chain compromise in 2023 of VPN software developed by a South Korean company, where the attackers replaced the legitimate installer with one that also deployed the group’s signature implant that we have named SlowStepper – a feature-rich backdoor with a toolkit of more than 30 components.

Key points of this blogpost:

• PlushDaemon is a China-aligned threat group, engaged in cyberespionage operations.
• PlushDaemon’s main initial access vector is hijacking legitimate updates of Chinese applications, but we have also uncovered a supply-chain attack against a South Korean VPN developer.
• We believe PlushDaemon is the exclusive user of several implants, including SlowStepper for Windows.
• SlowStepper has a large toolkit composed of around 30 modules, programmed in C++, Python, and Go.

Overview

In May 2024, we noticed detections of malicious code in an NSIS installer for Windows that users from South Korea had downloaded from the website of the legitimate VPN software IPany (https://ipany.kr/; see Figure 1), which is developed by a South Korean company. Upon further analysis, we discovered that the installer was deploying both the legitimate software and the backdoor that we’ve named SlowStepper. We contacted the VPN software developer to inform them of the compromise, and the malicious installer was removed from their website.

We attribute this operation to PlushDaemon – a China-aligned threat actor active since at least 2019, engaging in espionage operations against individuals and entities in China, Taiwan, Hong Kong, South Korea, the United States, and New Zealand. PlushDaemon uses a custom backdoor that we track as SlowStepper, and its main initial access technique is to hijack legitimate updates by redirecting traffic to attacker-controlled servers. Additionally, we have observed the group gaining access via vulnerabilities in legitimate web servers.

The victims appear to have manually downloaded a ZIP archive containing a malicious NSIS installer from the URL https://ipany[.]kr/download/IPanyVPNsetup.zip. We found no suspicious code on the download page (shown in Figure 1) to produce targeted downloads, for example by geofencing to specific targeted regions or IP ranges; therefore, we believe that anyone using the IPany VPN might have been a valid target.

Via ESET telemetry, we found that several users attempted to install the trojanized software in the network of a semiconductor company and an unidentified software development company in South Korea. The two oldest cases registered in our telemetry were a victim from Japan in November 2023, and a victim from China in December 2023.

Technical analysis

As illustrated in Figure 2, when the malicious IPanyVPNsetup.exe installer is executed, it creates several directories and deploys both legitimate and malicious files.

Additionally, the installer establishes persistence for SlowStepper by adding an entry named IPanyVPN to a Run key, with the value %PUBLIC%\Documents\WPSDocuments\WPSManager\svcghost.exe, so that the malicious component svcghost.exe (later extracted and deployed by the loader in EncMgr.pkg) is launched when the operating system starts.

The first malicious component that is loaded by the installer is the AutoMsg.dll loader. Figure 3 illustrates the major steps taken during the execution of this component.

When IPanyVPNSetup.exe calls ExitProcess, the patched bytes redirect execution to the shellcode that loads EncMgr.pkg into memory and executes it.

EncMgr.pkg creates two directories – WPSDocuments and WPSManager – in %PUBLIC%\Documents and the deployment begins by extracting components from the custom archives NetNative.pkg and FeatureFlag.pkg. The components are dropped to disk and moved to other locations with new filenames. The sequence and actions taken are as follows:

1. Extracts the files from NetNative.pkg to:

a. %PUBLIC%\Documents\WPSDocuments\WPSManager\assist.dll,

b. %PUBLIC%\Documents\WPSDocuments\WPSManager\msvcr100.dll,

c. %PUBLIC%\Documents\WPSDocuments\WPSManager\PerfWatson.exe, and

d. %PUBLIC%\Documents\WPSDocuments\WPSManager\svcghost.exe.

2. Deletes NetNative.pkg.

3. Moves FeatureFlag.pkg to C:\ProgramData\Microsoft Shared\Filters\SystemInfo\winlogin.gif.

4. Moves assist.dll to C:\ProgramData\Microsoft Shared\Filters\SystemInfo\Winse.gif.

5. Extracts file from Winse.gif to %PUBLIC%\Documents\WPSDocuments\WPSManager\lregdll.dll.

6. Copies data from BootstrapCache.pkg to %PUBLIC%\Documents\WPSDocuments\WPSManager\Qmea.dat.

Its last actions are to execute svcghost.exe using the ShellExecute API and then exit.

The svcghost.exe component performs monitoring of the PerfWatson.exe process, where the backdoor is loaded, ensuring that it is always running. If the processes are not running, it executes PerfWatson.exe (originally a legitimate command line utility named regcap.exe, included in Visual Studio), which the attackers abuse to side-load lregdll.dll.
